• VHF: Channels 2-13

UHF: Channels 14-69
Operating Bandwidth: 54 MHz to 806 MHz
Output Impedance: 300 ohms
(300 -75 ohm matching transformer included)
Dimensions:
Height of base: 3.375"
Height with Dipoles: Closed: 12.5", Open 42.5"
MSRP $9.95
Includes FREE UHF Loop Antenna for reception of channels 14-69
300 / 75 ohm matching transformer ensures compatibility with coaxial cable inputs
44" long 300 ohm flat connector wire fits even the largest rear projection televisions.
Weighted removable base includes non-slip pad for maximum stability
Heavy gauge 40" long retractable chrome VHF dipoles with safety tips
One Year Limited Warranty
Easily plugs into the antenna receptacle on most televisions

• Output Impedance: 75 ohms (75-300 ohm matching transformer included)

Operating Bandwidth:
VHF: 54 MHz-216 MHz (Channels 2-13)
UHF: 470 MHz-806 MHz (Channels 14-69)
AUX: 54 MHz-1000 MHz
Dimensions:
Base: 8"L x 4-1/4"D
Height of base: 2"
Height of base (including UHF loop): 9"
Length of dipoles: Closed 7-1/2", Open 44"
MSRP $19.95
Perfect set-top antenna for urban and suburban areas
Includes both VHF and UHF capability for reception of channels 2 through 69
Built-in Video Selector switch allows you to switch between broadcast TV and a video source, such as DVD, VCR or a video game.
6 ft. long 75 ohm coaxial cable allows the antenna to be installed on even the largest rear projection televisions
Includes VHF/UHF band separator and 75-300 ohm matching transformer for easy hook-up to any television set
Non-skid silicon base ensures maximum stability on any set-top

• Adjustable, ultra low noise amplifier helps to boost distant signals, or turn down the boost to prevent stronger signals from overpowering the desired channel
• Patented TERK Bypass system allows the signal to bypass the amplifier when it is turned off to help prevent signal loss for optimum results.
• Built-in Video Selector switch allows you to switch between broadcast TV and a video source, such as DVD, VCR or a video game.
• Includes both VHF and UHF capability for reception of channels 2 through 69
• 6 ft. long 75 ohm coaxial cable allows the antenna to be installed on even the largest rear projection televisions
• Includes VHF/UHF band separator and 75-300 ohm matching transformer for easy hook-up to any television set
• Non-skid silicon base ensures maximum stability on any set-top
• Amplifier Gain:
• VHF: 40dB adjustable
• UHF: 40dB adjustable
• Power Supply: AC to DC adapter 110V
• Operating Bandwidth: VHF: 54 MHz-26 MHz (Channels 2-13)
• UHF: 470 MHz-806 MHz (Channels 14-69)  AUX: 54 MHz-1000 MHz
• Dimensions:  Base: 8"L x 4-1/4"D  Height of base: 2"  Height of base (including UHF loop): 9"
• Length of dipoles: Closed 7-1/2", Open 44

Perfect set-top antenna in urban or suburban areas

Low-profile design stands just 4-3/4" high and  fits inside most television cabinets

Ultra-small footprint allows antenna to rotate freely atop most televisions

Includes both VHF and UHF capability for reception of channels 2 through 69

Includes VHF/UHF band separator and 75-300 ohm matching transformer for easy hook-up to any television set

6 ft. long 75 ohm cable allows the antenna to be installed on even the largest rear projection televisions

Non-skid silicon base ensures maximum stability on any set-top

Operating Bandwidth:

VHF: 54 MHz-250 MHz (Channels 2-13)

UHF: 470 MHz-806 MHz (Channels 14-69)

AUX: 54 MHz-1000 MHz

Output Impedance: 75 ohms (75-300 ohm matching transformer supplied)

Dimensions (with elements): 4-3/4"H x 25"W x 11-1/2"D

• Built-in Video Selector switch allows you to  switch between broadcast TV and a video  source, such as DVD, VCR or a video game.
• Low-profile design stands just 4-3/4" tall and fits in most television cabinets
• Includes both VHF and UHF capability for reception of channels 2 through 69
• Low-noise broadband amplifier features one-touch adjust and patented selectable bypass
• Includes VHF/UHF band separator and 75-300 ohm matching transformer for easy hook-up to any television set
• 6 ft. long 75 ohm cable allows the antenna to be installed on even the largest rear projection televisions
•  Non-skid silicon base ensures maximum stability on any set-top
• Operational Bandwidth:
• VHF: 54 MHz-216 MHz (Channels  2-13)
• UHF: 470 MHz-806 MHz (Channels 14-69)
• AUX: 54 MHz-1000 MHz
• Output Impedance: 75 ohms  (75-300 Ohm matching transformer supplied)
• Amplifier Gain: VHF: 40 dB adjustable UHF: 40 dB adjustable
• Dimensions (with elements): 4-3/4"H x 25"W x 11-1/2"D

• • TERK HDTV antennas include all the necessary hardware and manuals to be properly installed

• The TV32, TV36, and TV38 antennas have a bonus mounting kit to accommodate chimney, attic and wall installations
• The TV42 and TV44 can clip directly on to your existing satellite dish and requires no tools making installation easy
Quality & Performance
• All TERK antennas are made with high-quality, weather-resistant materials and high-performance components
TV32
Multi-Element
• CEA Color Code: Lt. Green
• Operating Bandwidth: UHF:470 MHz-806 MHz [Channels 14-69]• HDTV Compatible
• Elements: 13
• Antenna Weight: 2 lbs
• Dimensions: 22" W x 34" H
• Turning Radius: 11.25"
TV36
Multi-Element
• CEA Color Code: Red
• Operating Bandwidth: VHF:54 MHz-230 MHz [Channels 2-13] UHF: 470 MHz-806 MHz [Channels 14-69]
• HDTV Compatible
• Elements: 33
• Antenna Weight: 6.4 lbs
• Dimensions: 103.25" L x 111" W x 34" H
• Turning Radius: 69"
TV38
Multi-Element
• CEA Color Code: Red
• Operating Bandwidth: VHF:54 MHz-230 MHz [Channels 2-13] UHF: 470 MHz-806 MHz [Channels 14-69]
• HDTV Compatible
• Elements: 43
• Antenna Weight: 10 lbs
• Dimensions: 149.75" L x 111" W x 31.5"H
• Turning Radius: 90"
All Models
• Accessories Included:
[1] Chimney mount
[1] Wall mount
[1] Universal mount
[1] 5' foot mast
[1] Matching transformer
[1] Instruction manual

• Mounts onto any 18-inch satellite dish in minutes using patented TERK clips, with no tools required Precision-tuned receiving elements provide maximum local channel reception
• Built-in amplifier improves picture quality -- ideal for multiple TV installations No additional power supply required - amplifier is powered by the satellite receiver
• Ultra-durable weather-resistant construction
• TV42 features two built-in diplexers, enabling both satellite and local programming to be viewed from multiple TV sets at the same time Supplied with diplexers and connecting cables
• Amplifier gain: 10dB typical
• Output impedance: 75 Ohm
• Element type: broadband, single element
• Reception pattern: multidirectional
• Dimensions: 10 1/4" H x 21 1/4" W x 3 1/2" D
• TV 42 - 2 Inputs 2 outputs
• TV44 - 4 Inputs 4 Outputs

$79.95

• The TV55 indoor/outdoor amplified antenna is optimized for HDTV reception. The TV55's helical coil technology and patented dual-mode ultra-low-noise amplifier provide clear, powerful reception of HDTV and analog VHF/UHF broadcast signals, and its slim-profile design allows easy mounting under a windowsill, on a rooftop, on a wall or in any number of locations inside or outside a home.
• The TV55 includes cables and weatherproof stainless steel connectors, for easy integration with satellite systems. The kit combines local and satellite signals into a single RG6 coaxial cable-eliminating the need to run an extra wire from the dish to the home.
• Features:
• Patented helical coil broadband antenna element allows for a compact design while providing the performance of a larger antenna
• Dual-mode amplifier allows a choice of best gain setting-high-gain for weak signals or bypass mode for optimum reception of strong signals
• Amplifier is impedance-matched for best HDTV performance
• Ultra-durable weatherproof housing
• Can be mounted on top of an RV Includes "F" connector for connection to RG6 cable
• Multiple mounting options with all mounting hardware included
• Accessories included: (1) power injector with 110v AC to DC power adapter, (1) 1/4-20 x 1 1/2" hex-head bolt, (1) 1/4-20 2 1/2 hex-head bolt, (1) mast mount base, (2) 1/4-20 x 3/4" hex-head bolts, (1) mast mount cover, (1) 1/4-20 wing nut, (2) window mount brackets (2-piece assemblies), 1/4"-20 hexagon nuts, (2) wall mount cam-lock units, (2) #10 x 2 1/2" flat-head screws, (1) channel insert, (2) #8 x 1 1/2" flathead screws, (1) 9 3/4" flat coaxial cable, (2) 1/4" split washers, (1) 36" RG6 coaxial cable, (2) #10 plastic wall anchors.
• Amplifier gain: 10 dB
• Output impedance: 75 Ohm
• Operational bandwidth: 54 - 806 MHz
• Dimensions: 46" W x 3.5" H x 2.25" D

 With over 1,000 stations in more than 200 markets broadcasting digital television, nine out of ten households can now receive free HDTV signals with the right antenna, a set-top box and a high-definition television. Most of the antennas available today are large and unwieldy and need to be mounted outdoors or in a cramped attic. This is not an option if you live in an apartment or condo, or if you don’t want the hassle of installing an antenna yourself. The solution is a quality indoor antenna, which can pick up all local HDTV channels; one that will look great next to your television and one that is easy to install.

 The TERK HDTVi is the only indoor HDTV antenna optimized for both UHF and VHF reception (channels 2-69). The HDTVi elegantly solves the aesthetic challenge of integrating a log-periodic type element assembly into an indoor antenna. It is tuned for optimum HDTV reception with a unique design that utilizes log-periodic elements and dipoles for receiving both UHF and VHF HDTV broadcasts, allowing you to receive more stations. Its high gain picks up farther stations and its high back-to-front ratio rejects unwanted signals. The UHF antenna element can even be mounted vertically or horizontally to aid in better reception.

Specifications*
Technical Information:
 Operating Bandwidth:
 Bandwidth:12.5 MHz
VHF: Channels 2-13
UHF: Channels 14-69
Output Impedance: 75 Ohms
Dimensions  13.5" W x 9.12" H x 16.5" D
Height with dipoles extended: 42”



• Amplified Indoor HDTV/UHF/VHF Antenna
• Internal amplifier boosts signal reception
• Unique design utilizes log periodic tuned elements and dipoles
• Small footprint takes up less space





• Passive HDTV/UHF/VHF Indoor Antenna
• Engineered for reception of all local HDTV broadcasts
• Operating bandwidth covers both the UHF and VHF frequency ranges
• UHF (channels 2 û 13), VHF(channels 14 û 69)
• Utilizes a high-gain antenna array that can be oriented either horizontally or vertically
• Compact and easy to install atop or near a TV set
