Specifications
Number of Channels 1
Watts per Channel 4 Ohm
1 x 100
Watts per channel 2 Ohm
1 x 100
-
Distortion <1% THD Measured at
20-20KHz at rated power all channels driven
-
Signal to Noise Ratio >100dB A-Weighted
in 20KHz
-
Frequency Response 17Hz-21KHz +0,
-2dB
-
Input Sensitivity 100 mV - 8.5V
Unbalanced, 200 mV-17V balanced
-
Operational Voltage 10-16V
-
Dimensions 6.5 L x 5.81" W x 1.63"
H
-
Fully Regulated PWM power supply
Requires 10A Fuse
AUDIOPHILE
FULL SPECTRUM CLASS D TECHNOLOGY
The Xtant1.1i adds local and
global multiple nested feedback loops with premium MOSFETs and OPAmps for
switching stability and audio signal accuracy within the full range spectrum.
This results in an extremely high switching speed—over 1MHz.
Because the switching speed is
over 1MHz, we are able to set the output filter frequency high enough to
avoid any phase related distortion within the higher frequency range of
the audio signal. This enhances the musical reproduction by ensuring the
higher frequencies (cymbals and the like) compliment the entire frequency
range to bring new realism to the Class D amplifier sound experience.
The Audiophile Full Spectrum
Class D Technology with Xtant’s attention to detail results in a Class
D amplifier that sounds better than many audiophile Class A/B amplifiers.
It exhibits an extremely low noise floor eliminating the “hiss” common
to many Class D amplifiers. The improved dynamic range enables the accurate
reproduction of every loud and quiet passage within the musical range.
This makes the amplifier exceptionally suited for musical and theater applications.
Features
Xtant amplifiers feature a Fully
Regulated, Pulse Width Modulated power supply. This power supply technology
provides high efficiency and consistent output performance even when battery
voltage is less than optimum.
The Balanced input circuit increases
common mode noise rejection and eliminates ground loop noise while allowing
for 100mv to 17 volts of signal input. This circuit also makes interfacing
with any factory head-unit easy.
Both Thermal and Overcurrent
protection are incorporated into Xtant amplifiers. In the event of a problem,
the amplifier will reduce its power to maintain operation.
These small footprint mono-block
amplifiers are ideal for vehicles that have limited space and allows for
unlimited installation creativity in any application. The mono-block concept
also allows for easy audio and/or video system configuration (2-, 3-, 4-,
5-, 6-, or 7-Channel).
