Description
|
|
|
- Common Features
- * New HiFonics Illuminated Heat Sink Design
* Super D-Class Design
* Illuminated Blue Hifonics logo
* Illuminated MaxxSonics "M" Logo on end panel
* Control your Bass from the Drivers Seat with Dash Mountable "Remote
Bass Module" Included
* Heavy Duty Ultra -Fi Mosfets
* Brutus Pulse Wave EXVP (Exponential Variable Power Supply)
* Highly Efficient Super D-Class Amplifier circuitry with oversized
mosfet outputs
* HSMD - Hifonics Surface Mount Design
* Fully Adjustable Accu-Cross Crossovers
* Full PWM MOSFET Power Supply
* Line Output for Amplifier Daisy Chaining
* Twin-Turbo Torroid Coil Design
* HSMD Hifonics surface mount design
* balanced line outputs for our 18V line drivers
* Variable Bass Equilization (0-18 dB) @ 45 Hz
* Variable 24 dB/Octave Sub-Sonic Filter (15-35 Hz)
* 4 Guage Power and Ground Connections (2G on BXi-2008D)
* Maxxi-Fuse
* Power from the Gods Included
* Turn On Delay/Mute
* Frequency Response 20-250 Hz
* Damping Factor >250 (400 on BXi-2008D)
* S/N Ratio >95 dB
* THD and Noise < 0.1%
* Variable Input Level 0.2V - 9V (RCA/Unbalanced)
* Variable Input Level 0.4V - 18V (Mini DIN Balanced)
* DC/Short Circuit/Overload Protection Circuits
* Ultra-Fi MOSFET Power Output Circuit
* Phase Shift 0-180 Degrees
* Variable 24 dB/Octave Crossover (35-250 Hz)
* 12 Guage Speaker Connections (BXi-2008D 8 Guage Speaker Connections)
|
BXi 608
Brutus 1 x
600
RMS at 1 Ohm Class D Mono Subwoofer Amplifier
US$ 192.95
|
|
- Class A/B Design
- 150 watts RMS x
1 channels into 4 Ohms
- 300 watts RMS x
1 channels into 2 Ohms
- 600 watts RMS x
1 channel into 1 Ohms
- Dimensions 9.84"
L X 2.63" H X 10.39" W
Amplifier is not 600 RMS...
Not sure what the fuse size is but going off the bigger BXi's,
would most likely be 30-40 Amps.. Maxi fuse.. Make sure you put
amplifiers in perspective use a dirivative of Ohms law to determine
ACTUAL RMS values.. not psychological, overstated rms/peak
values.. P(Power in Watts) = I (Current in Amps) X E(Electromotive
Force or Voltage). Keep in mind that is theoretic, 100% EFFICIENCY,
meaning an ice cold amplifier with
no energy lost to heat.
|
BXi 1208D
Brutus 1 x
1200 RMS at 1 Ohm Class D Mono Subwoofer Amplifier
US$ 279.95
|
 |
- * 450 watts RMS x 1
channels into 4 Ohms
* 900 watts RMS x 1 channels into 2 Ohms
* 1200 watts RMS x 1 channel into 1 Ohms
* Dimensions 11.42" L X 2.52" H X 9.45" W
|
BXi 1608D
Brutus 1 x
1600 RMS at 1 Ohm Class D Mono Subwoofer Amplifier
US$ 314.95
|
|
- * 550 watts RMS x 1
channels into 4 Ohms
* 1100 watts RMS x 1 channels into 2 Ohms
* 1600 watts RMS x 1 channel into 1 Ohms
* Dimensions 14.17" L X 2.52" H X 9.45" W
|
BXi 2008D
Brutus 1 x
2000 RMS at 1 Ohm Class D Mono Subwoofer Amplifier
US$ 389.95
|
|
- * 650 watts RMS x 1
channels into 4 Ohms
* 1300 watts RMS x 1 channels into 2 Ohms
* 2000 watts RMS x 1 channel into 1 Ohms
* Dimensions 14.97" L X 2.52" H X 9.45" W
|
BXi 2608D
Brutus 1 x
2600 RMS at 1 Ohm Class D Mono Subwoofer Amplifier
US$ 514.95
|
|
- * 850
watts RMS x 1 channels into 4 Ohms
* 1700 watts RMS x 1 channels into 2 Ohms
* 2600 watts RMS x 1 channel into 1 Ohms
* Dimensions 17.72" L X 2.52" H X 9.45" W
|
